Integrated Circuit & System (i-CAS) Lab

The Integrated Circuit & System (i-CAS) Lab was established in 2015 under the financial assistance from Ministry of Electronics & Information Technology, Government of India through SMDP Chip-to-System Design project. It's one of the core labs in the department of Electronics & Communication Engineering at National Institute of Technology, Arunachal Pradesh, India. As the name suggests, this lab facilitates the commercial EDA tools like Cadence, Synopsys, Mentor Graphics and Xilinx, where extensive research is carried out on VLSI Circuits & Systems and Post-CMOS Technologies. Our goal is to initiate, steer, realize and contribute to the understanding of real life problems in circuit designs so as to come up with breakthroughs for comfortable and better tomorrow.

EDA Tool Facility
Cadence Design System
  • Circuit & Layout Design → Virtuoso
  • Circuit Simulation → Spectre
  • DRC & LVS → Assura
  • RC extraction → Quantus QRC
  • Synopsys EDA
  • Device Simulation → 3D TCAD University Bundle
  • Circuit & Layout Design → Custom Compiler
  • Circuit Simulation → Hspice
  • DRC & LVS → IC Validator/Hercules
  • RC extraction → Star RC
  • Mentor Graphics EDA
  • Circuit & Layout Design → Pyxis
  • Circuit Simulation → Eldo
  • DRC & LVS → Calibre
  • RC extraction → xRC
  • Xilinx

    Vivado Design Suite

    RSoft CAD
  • RSoft CAD
  • BeamPROP tool
  • FEMSIM tool
  • Workstation & PC
    HP Z440 Workstation
  • INTEL(R)XEON(R)CPU
  • E5-1607v3@3.10GHZ(4CPUs)
  • Base Clock ~3.05GHz
  • DDR4 RAM: 4 GB
  • Total Count = 05
  • HP 406 G1 MT
  • INTEL(R)CORE(TM)i5-4590
  • CPU @3.30GHz(4CPUs)
  • Base Clock ~3.3GHz
  • DDR3 RAM: 8 GB
  • Total Count = 25
  • Chip Tapeout
    Chip Tape Out - 01
  • Serializer-cum-PDCG
  • Technology: SCL 180nm
  • Package: QFN
  • Die: 2mm x 2mm
  • Pin Count: 48
  • Students: Pritam, Madhu, Sandeep
  • Collaborators (Present & Past)
    Dr. Bidyut K Bhattacharyya, Fellow IEEE e-mail

    Georgia Tech, Atlanta, USA

    Designation: Research Engineer
    Department: Packaging Research Center
    Research Interest: Power Delivery, Packaging
    Dr. Hanjung Song e-mail

    Inje University, Gimhae, Korea

    Designation: Professor
    Department: Nanoscience and Engineering
    Research Interest: Circuit Design, Memristor
    Dr. Saraju P Mohanty, SM IEEE e-mail

    University of North Texas, USA

    Designation: Professor
    Department: Computer Science & Engineering
    Research Interest: Consumer Electronics, CPS
    Dr. Saeid Gorgin e-mail

    Iranian Research Organization for S & T, Tehran

    Designation: Assistant Professor
    Department: Computer Engineering
    Research Interest: Computer Arithmetic, VLSI
    Dr. Abir Jyoti Mondal e-mail

    NIT Arunachal Pradesh, India

    Designation: Assistant Professor
    Department: Electronics & Communication
    Research Interest: Digital & Analog IC
    Lab Achievements / Gallery
    With Students at ESIC-2020, Itanagar, India
    Lunch with ECE Faculties / Staff - 2019
    AICTE Visit-2019, New Delhi
    Best Paper Award, ICCACCS-2018, Kolkata
    Best Research Award, AshTech-2018, Indore
    NIT AP Convocation-2018 with Students
    Best Paper Award, ICEIC-2017, Phuket
    After Presentation at ICEIC-2017, Phuket
    Visited CoreEL Bangalore, 2016
    With Prof. Bhattacharyya (Supervisor) at Kolkata, 2015
